Rolling shutters are mounted over windows, doors, patios or anywhere a secure insulated barrier is needed. The interlocking slats are aluminum and filled with dense ecologic foam for insulation and rigidity. The foam core stops 99% of the radiant heat from entering your space. This insulation combined with the “dead air” space between the shutter and the glass, makes a rolling shutter one of the best products available to stop heat, cold, sound, and light.
- The best insulation for windows & doors
- Stop heat and save energy
- Total privacy
- No more glare on your TV
- Room darkening
- Reduce noise up to 60%*
- The ultimate security
- Motorized, radio remote, wall switch, or home automation
- Enclose your patio
- Manual Overrides for safety
- LIFETIME warranty on our Tucson Signature Series Motors and Electronics
With the shutter completely closed you have complete privacy, sound reduction, 99% room darkness, and the ultimate security.
- Light Beige
- Dark Beige
*All claims are based on third party testing provided by TRS or the vendors of our raw goods. We can provide copies of the testing results.
Insulation or Security?
More customers purchase rolling shutters for insulation than security. The ecologic foam reduces the conduction of heat and cold. If you were to cut open your refrigerator you would find the same type of foam preventing the heat from getting in or cold from getting out. Additionally, when rolled down a “dead air” space is created between the window and the shutter. This greatly increases the energy resistance value. Rolling shutters will save on the cost of energy needed to heat or cool your home.
This home located in Alaska (pictured below), has rolling shutters to help keep the cold winters out and the heat in. However, they also use the shutters in the summertime to keep the heat out. Due to the large amount of glass they still get elevated temperatures and with no air conditioning the shutters allow them to keep the house comfortable.
44mm Standard Slat
Rolling shutter slats are made of aluminum and filled with a very dense ecologic foam for added strength and superior insulation value. The standard 44mm slat is our most commonly used slat. • Roll formed aluminum slat • Powder coated finish for longevity • Six standard colors • Used for applications just under 12 feet wide* • Slats interlock together to prevent separation under load • Not used for patio openings or hurricane areas
55mm Patio Slat
The patio slat is used for wider openings and free expanses between posts or columns. • Injected with an ecologic foam for insulation and rigidity • Roll-formed aluminum slat • Powder coated finish for longevity • 4 standard colors 2 special order • Used on applications up to 16 feet wide* • Slats interlock together to prevent separation under load
44mm Extruded Slat
Used for added strength beyond the standard foam fill slat. Additional security. Increased impact resistance. • Extruded aluminum slat with XX wall • Hollow center no foam. Dead air insulation • Powder coated finish for longevity • Six standard colors or custom powder coating available • Slats interlock to prevent separation under load
55mm Heavy Duty Extruded Slat
Used for added strength beyond the standard foam fill slat. Additional security. Increased impact resistance. • Extruded aluminum thick walled slat • Hollow center no foam. Dead air insulation • Powder coated finish for longevity • Six standard colors or custom powder coating available • Slats interlock to prevent separation under load
Rolling Shutter Housing
All housings are made from aluminum in roll-formed or extruded. Aluminum gives heavy-duty strength in a lightweight material that resists corrosion. Powder coating adds even greater durability and beauty to your shutters.
44mm Standard Guide Rail
Extruded aluminum side rails guide and retain the slats as they travel up or down. Guide rails are powder coated and have a removable felt runner that cushions the slats.
55mm Patio Guide Rail
Extruded aluminum side rails guide and retain the slats as they travel up or down. Patio guide rails are deeper to retain the slat better in windy conditions. Guide rails are powder coated and have a removable felt runner that cushions the slats.
Motorization & Electronics
Radio Remote Square Style Handheld 15 Channel & Single Channel
Radio remote handheld transmitter will operate your shutters through walls and floors inside or out. Magnetic wall mounted base makes this remote both a handheld and wall mounted for convenience. 15 Channel: Operate 15 different shutters or 15 groups of shutters. Includes a master channel to operate everything programmed simultaneously. Single channel to operate one shutter or one group of shutters.
Radio Remote Round Style Handheld 15 Channel & Single Channel
Radio remote handheld transmitter will operate your shutters through walls and floors inside or out. 15 Channel: Operate 15 different shutters or 15 groups of shutters. Includes a master channel to operate everything programmed simultaneously. Single channel to operate one shutter or one group of shutters.
Radio Remote Wall Switch 15 Channel & Single Channel
Wireless radio remote wall switch. Operate 15 different shutters or 15 groups of shutters. Includes a master channel to operate everything programmed simultaneously. Can be mounted on the wall or used as a portable table top remote. Single Channel to operate one shutter or one group of shutters.
T-Block Locking Feature
Rolling shutters lock when completely in the down and closed position. The T-Block spring loaded hinge system forces the slats down into a locked position. The slats cannot be pushed up or forced open until operated in the opposite direction. This system was created and designed by the owner and the VP of TRS.
Manual Override-Crank Wand
A crank wand is used to override ride an electric shutter for opening during an emergency. Even without power the manual crank wand will raise a rolling shutter using internal gears attached to the motor. Building codes require that each sleeping room has at least one manual means as direct egress to the exterior of a building. Crank Wands can be used to manually operate a basic rolling shutter from the inside of your home without a motor.
Manual Strap Operation
Pull Strap: A Nylon strap is pulled from inside your home to operate smaller rolling shutters. Crank Strap: A nylon strap fed into a crank box mounted inside your home. The strap pulls the shutter up and down when the crank handle is turned. *The strap operations cannot use the T-Block locking feature.
Securing Businesses Across North America
Want piece of mind when your business is closed? Our aluminum exterior rolling shutters are the ultimate protection over your doors and windows. Auto locking features make shutters very convenient. Just push a button and secure your entire business. Radio remotes with secure code hopping Heavy duty exterior key switches Manual Overrides Alarm system interface Different grades of slat to choose from
Additional Commercial Appilcations
Open and inviting during business hours. Shutters roll up into the aluminum housing at the top. Open with a key switch or radio remote control for security.
Locked down after hours for maximum protection.
